An introduction to Johanson Dielectrics

Johanson Dielectrics is a specialist manufacturer of high performance multilayer ceramic capacitors headquartered in Sylmar, California, in the San Fernando valley to the north of Los Angeles.

They produce surface mount and leaded devices for commercial, RF/microwave, high voltage, SMPS and high temperature industrial and down hole applications.

They also produce planar arrays and ceramic capacitor substrates.

Johanson Dielectrics Surface Mount Multilayer Ceramic Capacitors

JDI surface mount MLC capacitors include

• standard commercial grade chips,

• high voltage chips,

• chips optimized for AC power applications

• flexible termination devices

• Class X and Y capacitors

• tantalum replacement chips

• Tip & Ring chip capacitors

• X2Y filter and decoupling capacitors

---

Johanson Dielectrics Leaded Multilayer Ceramic Capacitors

JDI radial leaded multilayer ceramic capacitors include:

• high capacitance stacked capacitors in DIL packages for SMPS applications

• radial leaded SMPS capacitors

• high capacitance, small size mini-switchmode capacitors

• base metal electrode (BME) mini-switchmode capacitors

• high voltage radial leaded capacitors

• high temperature molded radial leaded capacitors

• high temperature stacked capacitors in DIL packages

---

Planar Arrays & Capacitor Substrates

---
